3.4.6 Group H: Extension Card Parameters
H0: Extension card general parameters
Code Name Setting range Default Min. Attri.
H0.00 Control word 00000...0FFFF 00000 1 Run
H0.01 Status word – 00000 – Read
H0.10 Frequency command 0.00...655.35 0.00 0.01 Run
H0.12
Torque control reference from
fieldbus
0.0...6553.5 0.0 0.1 Run
H0.14
FWD torque limitation reference
from fieldbus
0.0...6553.5 0.0 0.1 Run
H0.15
REV torque limitation reference
from fieldbus
0.0...6553.5 0.0 0.1 Run
H0.16
Speed limitaion at torque control
mode from fieldbus
0.00...655.35 0.00 0.01 Run
H0.18 Opt 1 active interface version – – 0.01 Read
H0.19 Opt 2 active interface version – – 0.01 Read
H0.20 Extension card 1 type 0: None
1: PROFIBUS card
2: CANopen card
8: I/O card
9: Relay card
10: IO plus card
0 – Read
H0.30 Extension card 2 type 0 – Read
H0.23 Extension card 1 firmware version – – 0.01 Read
H0.33 Extension card 2 firmware version – – 0.01 Read
H0.50 Fieldbus voltage command 0.00...100.00 % 0.00 0.01 Run
EFC 3610 / EFC 5610 Bosch Rexroth AG
Start-up
DOK-RCON03-EFC-X610***-QU11-EN-P
67/87
