H9: Relay card parameters
Code Name Setting range Default Min. Attri.
H9.00 Extended relay 1 output selection
0...25
0 – Stop
H9.01 Extended relay 2 output selection 0 – Stop
H9.02 Extended relay 3 output selection 0 – Stop
H9.03 Extended relay 4 output selection 0 – Stop
H9.10 Relay output setting value
Relay1 is defined by bit0,
when bit0 is '0', R1b_R1a
is opend; when bit0 is '1',
R1b_R1a is closed
Relay2 is defined by bit1,
when bit1 is '0', R2b_R2a
is opend; when bit1 is '1',
R2b_R2a is closed
Relay3 is defined by bit2,
when bit2 is '0', R3b_R3a
is opend; when bit2 is '1',
R3b_R3a is closed
Relay4 is defined by bit3,
when bit3 is '0', R4b_R4a
is opend; when bit3 is '1',
R4b_R4a is closed
0 – Run
H9.97 Relay card output channel diagnosis
0: Inactive
1: Relay1 diagnosis
2: Relay2 diagnosis
3: Relay3 diagnosis
4: Relay4 diagnosis
5: All output diagnosis
0 – Stop
Setting range of H9.00...H9.03:
0: Converter ready
1: Converter running
2: Converter DC-braking
3: Converter running at zero speed
4: Speed arrival
5: Frequency level detection signal (FDT1)
6: Frequency level detection signal (FDT2)
7: Simple PLC stage complete
8: Simple PLC cycle complete
10: Converter undervoltage
Bosch Rexroth AG
Start-up
EFC 3610 / EFC 5610
76/87
DOK-RCON03-EFC-X610***-QU11-EN-P
