E2: Output terminal parameters
Code Name Setting range Default Min. Attri.
E2.01 DO1 output setting 0...25 1 – Stop
E2.02 DO1 pulse output setting
0: Converter output frequency
1: Converter output voltage
2: Converter output current
3: Setting torque
4: Output torque
0 – Stop
E2.03
Pulse output maximum
frequency
0.1...32.0 kHz 32.0 0.1 Run
E2.15 Relay1 output selection 0...25 1 – Stop
E2.20
DO1/relay1 output values from
extension card fieldbus commu-
nication
Bit0: 0 (open collector is
opened); 1(open collector is
closed)
Bit8: 0 (Tb_Ta is opened);
1(Tb_Ta is closed)
0 – Run
E2.25 AO1 output mode
0: 0...10 V
1: 0...20 mA
0 – Run
E2.26 AO1 output setting
0: Output frequency
1: Setting frequency
2: Output current
4: Output voltage
5: Output power
6: AI1 analog input
7: AI2 analog input
8: EAI1 analog input
9: EAI2 analog input
11: Motor temperature sensor
power supply
12: Parameter setting from com-
munication
②
13: Setting torque
14: Output torque
0 – Run
E2.27 AO1 gain 0.00...10.00 1.00 0.01 Run
E2.28
AO1 value in percentage from
extension card fieldbus commu-
nication
0.00...100.00 % 0.00 0.01 Run
EFC 3610 / EFC 5610 Bosch Rexroth AG
Start-up
DOK-RCON03-EFC-X610***-QU11-EN-P
55/87
