Code Name Setting range Default Min. Attri.
E2.40 Rated voltage
1P 200...240 VAC 220
1 Stop
3P 380...480 VAC 380
E2.50 Output curve 1 minimum 0.0 %...[E2.52] 0.0 0.1 Run
E2.51 Output curve 1 minimum value 0.00...100.00 % 0.00 0.01 Run
E2.52 Output curve 1 maximum [E2.50]...100.0 % 100.0 0.1 Run
E2.53 Output curve 1 maximum value 0.00...100.00 % 100.00 0.01 Run
E2.70 Frequency detection width 0.00...400.00 Hz 2.50 0.01 Run
E2.71 Frequency detection level FDT1 0.01...400.00 Hz 50.00 0.01 Run
E2.72
Frequency detection level
FDT1 width
0.01...[E2.71] Hz 1.00 0.01 Run
E2.73 Frequency detection level FDT2 0.01...400.00 Hz 25.00 0.01 Run
E2.74
Frequency detection level
FDT2 width
0.01...[E2.73] Hz 1.00 0.01 Run
E2.80 Counter middle value 0...[E2.81] 0 1 Run
E2.81 Counter target value [E2.80]...9,999 0 1 Run
Setting range of E2.01 and E2.15:
0: Converter ready
1: Converter running
2: Converter DC-braking
3: Converter running at zero speed
4: Speed arrival
5: Frequency level detection signal (FDT1)
6: Frequency level detection signal (FDT2)
7: Simple PLC stage complete
8: Simple PLC cycle complete
10: Converter undervoltage
11: Converter overload pre-warning
12: Motor overload pre-warning
13: Converter stop by external error
14: Converter error
15: Converter OK
16: Counter target value arrival
17: Counter middle value arrival
18: PID reference engineering value arrival
19: Pulse output mode enable(only available with DO1 output selection)
Bosch Rexroth AG
Start-up
EFC 3610 / EFC 5610
56/87
DOK-RCON03-EFC-X610***-QU11-EN-P
