①
:
The relationship between the output of '21: Parameter setting from
communication' and communication mode is as follow:
● For modbus mode,
– The output of parameter H8.20 is defined by bit0 of register
0x7F09. When bit0 is '0', open collector is opened; when bit0 is
'1', open collector is closed.
– The output of parameter H8.21 is defined by bit8 of register
0x7F09. When bit8 is '0', ETb_ETa is opened; when bit8 is '1',
ETb_ETa is closed.
– The output of parameter H8.22 is defined by bit1 of register
0x7F09. When bit1 is '0', open collector is opened; when bit1 is
'1', open collector is closed.
● For other fieldbus mode, the output is defined by patameter
H8.23.
②
:
The relationship between the output of '12: Parameter setting from
communication' and communication mode is as follow:
● For modbus mode, the output is defined by register 0x7F07, the
value range of register is 0.00 %...100.00 % (It means percentage
of maximum analog output value).
●
For other fieldbus mode, the output is defined by patameter
H8.28.
EFC 3610 / EFC 5610
Bosch Rexroth AG
Start-up
DOK-RCON03-EFC-X610***-QU11-EN-P
75/87
