Page #48 background imageLoading...
Page #48 background image
Code Name Setting range Default Min. Attri.
C0.30
Converter overload
pre-warning delay
0.0...20.0 s 2.0 0.1 Stop
C0.40
Power loss ride-
through mode
0: Inactive; 1: Output disa-
bled
2: Regain kinetic energy
3: Regain kinetic energy,
decelerate to stop
0 Stop
C0.41
Power loss ride-
through recovery delay
0.10...30.00 s 0.50 0.01 Stop
C0.42
Power loss ride-
through action voltage
1P 200 VAC: 216...366 V 240
1 Stop
3P 400 VAC: 406...739 V 440
C0.43
Power loss ride-
through recover voltage
1P 200 VAC: 223...373 V 250
1 Stop
3P 400 VAC: 413...746 V 450
C0.44
Power loss ride-
through deceleration to
stop time
0.1...6,000.0 s 5.0 0.1 Stop
C0.50 Fan control
0: Automatically controlled
1: Always on
0 Run
C0.51 Fan total running time 0...65,535 h 0 1 Read
C0.52 Fan maintenance time 0...65,535 h (0: Inactive) 0 1 Stop
C0.53
Fan total running time
reset
0: Inactive; 1: Active
Resets to '0' after action is
executed
0 Run
: this parameter is only available with models of 5K50 and above.
: the parameters are only available with models of 22K0 and below.
: percentage of frequency converter rated current.
Setting range of C0.25:
0: Both disabled
1: Stall overvoltage protection enabled, resistor braking disabled
2: Stall overvoltage protection disabled, resistor braking enabled
3: Stall overvoltage protection enabled, resistor braking enabled
Setting range of C0.28:
0: Both input and output phase loss protection active
1: Only input phase loss protection active
2: Only output phase loss protection active
3: Both input and output phase loss protection inactive
Bosch Rexroth AG
Start-up
EFC 3610 / EFC 5610
42/87
DOK-RCON03-EFC-X610***-QU11-EN-P
