REXROTH EFC 3610 Series Quick Start Guide

Code Name Setting range Default Min. Attri.
H1.10
Output PZD 1
①
0: Not used
1: Control word
2: Frequency command
3: Empty PZD
4: ASF command 1
5: ASF command 2
6: ASF command 3
7: ASF command 4
8: ASF command 5
9: ASF command 6
10: ASF command 7
11: ASF command 8
12: Torque command
13: Forward torque limit
14: Reverse torque limit
15: Speed limit in torque mode
16: DO1/relay1 output values (see pa-
rameter E2.20)
17: AO1 value in percentage (see pa-
rameter E2.28)
18: EDO values (see parameter H8.23)
19: EAO value in percentage (see pa-
rameter H8.28)
20: Relay card output values (see pa-
rameter H9.10)
21: V/f separation voltage command in
percentage (see parameter H0.50)
1
1 Stop
H1.11 Output PZD 2 2 1 Stop
H1.12 Output PZD 3 0 1 Stop
H1.13 Output PZD 4 0 1 Stop
H1.14 Output PZD 5 0 1 Stop
H1.15 Output PZD 6 0 1 Stop
H1.16 Output PZD 7 0 1 Stop
H1.17 Output PZD 8 0 1 Stop
H1.18 Output PZD 9 0 1 Stop
H1.19 Output PZD 10 0 1 Stop
EFC 3610 / EFC 5610 Bosch Rexroth AG
Start-up
DOK-RCON03-EFC-X610***-QU11-EN-P
69/87
