Code Name Setting range Default Min. Attri.
H8.26 EAO output selection
0: Running frequency
1: Set frequency
2: Output current
4: Output voltage
5: Output power
6: AI1 analog input
7: AI2 analog input
8: EAI1 analog input
9: EAI2 analog input
11: Motor temperature sen-
sor power
12: Parameter setting from
communication
②
13: Setting torque
14: Output torque
0 – Run
H8.27 EAO gain 0.00...10.00 1.00 0.01 Run
H8.28
EAO value in percentage from exten-
sion card fieldbus communication
0.00...100.00% 0.00 0.01 Stop
H8.30 EAI2 input mode
0: 0...20 mA
1: 4...20 mA
2: 0…10 V
3: 0…5 V
4: 2...10 V
5: -10...10 V
0 – Stop
H8.31 EAI2 input polarity setting
0: Polarity inactive
1: Polarity active without di-
rection control
2: Polarity active with direc-
tion control
1 – Stop
H8.32 EAI2 filter time 0.000...2.000 0.100 0.001 Run
H8.33 EAI2 gain 0.00...10.00 1.00 0.01 Run
H8.34 EAI2 curve minimum -120.0 %...[H8.36] 0.0 0.1 Run
H8.35 EAI2 curve minimum value -[E0.09]…[E0.09] 0.00 0.01 Run
H8.36 EAI2 curve maximum [H8.34]...120.0 % 100.0 0.1 Run
H8.37 EAI2 curve maximum value -[E0.09]…[E0.09] 50.00 0.01 Run
H8.38 EAI2 dead zone filter value 0.0...30.0 % 0.0 0.1 Run
Bosch Rexroth AG
Start-up
EFC 3610 / EFC 5610
72/87
DOK-RCON03-EFC-X610***-QU11-EN-P
