3 Ratings and Dimensions
3.1 Ratings
A distributed drive controller KMS may only be operated in con‐
junction with an electronic control system KCU.
UL Ratings and Dimensions
Description Symbol Unit KMS01.2B-A018
Listing according to UL standard (UL) UL 508 C
Listing according to CSA standard (UL) Canadian National Standard(s) C22.2 No. 14-10
UL files (UL) E134201
Ambient temperature range for operation with
nominal data
T
a_work
°C 0…40
Degree of protection according to IEC60529 IP 65
Ambient conditions according to UL50/50E 4X Indoor Use Only
Mass m kg 2,40
Data control voltage
Rated control voltage input (UL)
1)
U
N3
V DC 30…42
Rated power consumption control voltage input
at U
N3
(UL)
2)
P
N3
W 15,5
Data power section
Short circuit current rating (UL) SCCR A rms 42000
Rated input voltage, power (UL)
3)
U
LN_nenn
V DC 540…750
Rated input current (UL)
I
LN
A 7,3
Maximum bypass current (UL) A 25,0
Output voltage (UL)
U
out
V 3 x AC 0…530
Output current (UL)
I
out
A 6,0
Output frequency range (UL)
4)
f
out
Hz 0…800
Power dissipation at continuous current and
continuous DC bus power respectively (UL)
5)
P
Diss_cont
W 50,00
Last modification: 2010-09-20
1) Observe supply voltage for motor holding brakes
2) HMS, HMD, HCS plus motor holding brake and control section;
HCS01 including control section
3) DC bus L+, L-; mains input L1, L2, L3
4) Depending on switching frequency which was set in parameter
P‑0‑0001
5) Plus dissipation of braking resistor and control section
Fig.3-1: KMS - UL Ratings and Dimensions
