Badly grounded control cabinet doors act as antennas. Therefore, connect
the control cabinet doors to the cabinet on top, in the middle and on the bot‐
tom via short equipment grounding conductors with a cross section of at least
6 mm
2
or, even better, via grounding straps with the same cross section.
Make sure connection points have good contact.
6.2.3 Control Cabinet Mounting According to Interference Areas - Exempla‐
ry Arrangements
Supply Units With Regeneration
Do not operate any additional loads at the mains filter!
Do not operate any other loads at the connection from the mains
filter output to the mains connection of the supply unit.
For motor blowers and power supply units, for example, use sep‐
arate mains filters.
DOK-INDRV*-KMS01******-IT01-EN-P
Rexroth IndraDrive Mi Distributed Drive Controller KMS01
Bosch Rexroth AG 49/67
EMC Measures for Design and Installation
