5.3 Commissioning, Operation, Diagnostics and Maintenance
5.3.1 Notes on Commissioning
General Information
High electrical voltage! Danger to life, electric
shock and severe bodily injury!
Read and observe the detailed safety instructions contained in this documen‐
tation in chapter "Important Notes".
Preparation
1. Keep the documentation of all used products ready.
2. Check the products for damage.
3. Check all mechanical and electrical connections.
4. Activate safety devices and monitoring systems of the installation.
How to Proceed
When all requirements have been fulfilled, commission the drive system ac‐
cording to the instructions contained in the corresponding product documen‐
tation. See the Functional Description of the firmware for the corresponding
information.
The commissioning of controllers and control unit can require additional
steps. The check of functionality and performance of the installations is not
part of motor commissioning; instead, it is carried out within the scope of the
commissioning of the machine as a whole. Observe the information and regu‐
lations of the machine manufacturer.
5.3.2 Notes on Operation
Make sure that the ambient conditions described are complied with during
operation.
5.3.3 Diagnostic Functions
Diagnostic Display KSM/KMS
LED H14
Fig.5-10: LED H14 (Example KSM)
At the device, there is a tricolor LED which displays the drive status.
Bosch Rexroth AG DOK-INDRV*-KMS01******-IT01-EN-P
Rexroth IndraDrive Mi Distributed Drive Controller KMS01
38/67
