REXROTH IndraDrive Mi - Page 37

Hybrid cable RKH
(with different outgo‐
ing directions from
connection point
X3.1 or X3.2 at KSM
and KMS)
KCU X3.1 X3.1 X3.1 X3.2 X3.2 X3.2 RKH0700
X3.2
RKH030
1
- - -
RKH000
2
RKH0101 RKH0203 RKH0203
X3.2
RKH040
1
- - -
RKH010
1
RKH0201 RKH0205 RKH0205
X3.2
RKH050
1
- - -
RKH020
3
RKH0205 RKH0601 RKH0601
RKH070
0
RKH050
1
RKH020
2
RKH020
4
RKH060
0
RKH020
3
RKH0205 RKH0601 -
Fig.5-6: Hybrid Cable RKH
