Richard Wolf 2271 - Illustration and Setup; Front Panel; Front Panel Legend

6
GA--A 181
2Illustration
2.1 Front panel
3
4
5
2
6
7
1
2.1.1 Legend
1 Power switc h with green LED 5 “Foot switch actuated” indicator lamp
2 Socket for foot switch 6 “Transducer malfunction” warning lamp
3 Connection bar for transducer 7 “Generator malfunction” alarm lamp
4 Intensity button for power stage preselection
