1 General information
1.1 Symbols
Symbols
Meaning
Attention, consult ACCOMPANYING DOCUMENTS
Off (disconnection from mains/power)
On (connection to mains/power)
Equipotentality
Fuse
µ
Alternating current (AC)
TYPE BF APPLIED PART
Intensity preselection, stage III
Intensity preselection, stage II
Intensity preselection, stage I
Fault indicator “Generator malfunction” warning lamp
Fault indicator ”Transducer malfunction” warning lamp
Standby indicator, “Device output active” lamp (foot switch actuated)
Socket for foot switch
Interface symbol/device output (e.g. RIWO NET SYSTEM)
Interface symbol/device input (e.g. RIWO NET SYSTEM)
Socket, 4--pole, control output (Suction Pump)
REF
Order number
A Registered Trademark of ETL, a Recognized Testing Laboratory , listing compliance as
Medical Electrical Equipment to standard CAN/CSA C 22.2 No. 601.1 (c) and UL 60601--1 (us)
Identification in conformity with Medical Devices Directive 93/42/EEC only valid if the product
and/or packagingis marked with this symbol. Products of category IIa and above, as well as
sterile products or products with measuring function of category I, are additionally marked with the
code number of the notified body (0124).
