8.2 Technical data
8.2.1 Electrical connection
Model/type
Voltage
V
µ
Frequency
Hz
Power
consumption
VA
Current
rating
A
Fuse
A
2271.001 230 50 / 60 200 0.9 T1.25L
2271.002 100 50 / 60 200 2.0 T2.50L
2271.003 110 / 115 50 / 60 200 1.8 T2.50L
2271.004 120 / 127 50 / 60 200 1.7 T2.50L
2271.101 230 50 / 60 200 0.9 T1.25L
2271.102 100 50 / 60 200 2.0 T2.50L
2271.103 110 / 115 50 / 60 200 1.8 T2.50L
2271.104 120 / 127 50 / 60 200 1.7 T2.50L
8.2.2 Technical data of ultrasound generator
Electromagnetic compatib ility (EMC) to IEC / EN 60601 --1--2
Medical Devices Directive 93/42/EEC Class II b
Protection against electric shock see transducer
Protection class to IEC / EN 60601 --1;
(UL 2601--1 / CSA C22.2 No.601.1 -- for USA)
I
Degree of protection against the ingression of liquid IP 20 (Not protected)
Duty factor
Continous operation with load interval
(INT.20sec/20sec)
Noise level 75 dB(A)
Degree of protection in the presence of flammable gasses
This device is not protected against explosions
(Do not operate this device in flammable environments)
Weight 8.5 kg (18.7 lbs)
Dimensions WxHxD 320 mm x 105 mm x 360 mm
8.2.3 Interfaces of ultrasound generator
Transducer output 1 x connector strip, 2 x 9--pole
Footswitch output connector 1 x socket, 3 --pole
Suction device output socket (Suction Pump) 1 x socket, 4 --pole
Connectors for RIWO NET SYSTEM (option) 2 x socket, 9 --pole
