Display Panel
The display panel shows machine status, error messages, and function menus.
A force or impact of more than 30 N (about 3 kgf) will damage the display panel.
If you press the [User Tools/Counter] key, the User Tools menu screen appears.
Using the System Settings menu screen as an example, this section explains how to use the machine's
display panel.
BKR002S
1. The settings menu appears. Press the [ ] or [ ] key to scroll to the setting you want to specify or
change, and then press the [OK] key to display the screen for specifying that setting.
2. The number of pages in the displayed settings menu appears. If you cannot see the entire menu, press
the [ ] or [ ] key to scroll the screen.
Reading the Display and Using Keys
This section explains how to read the display and use the Selection keys.
If you press the [Copy] key, the initial copy screen appears.
Using the initial copy screen menu as an example, this sections how to use the machine's control panel.
BKR003S
1. Scroll keys
16
