CMYK Simulation Profile
You can simulate the color tone of the printing ink.
You can select the printing ink from US OffsetPrint, Euroscale and JapanColor.
Windows 2000 / XP / Vista, Windows Server
2003 / 2003 R2
[CMYK Simulation Pofile] on [Document Options]
on the [Advanced] tab in the Printing Preferences
dialog box.
Mac OS
[CMYK Simulation Profile] on [Printer Specific
Options] in the print dialog box.
Mac OS X
[CMYK Simulation Profile] on the [Features x] tab
on [Printer Features] in the print dialog box.
Image Smoothing
Use this to select the image smoothing type.
The following table shows the tabs or menus where you can select this function.
Windows 2000 / XP / Vista, Windows Server
2003 / 2003 R2
[Image Smoothing] on [Document Options] on the
[Advanced] tab in the Printing Preferences dialog
box.
Mac OS
[Image Smoothing:] on [Printer Specific Options] in
the print dialog box.
Mac OS X
[Image Smoothing:] on the [Features x] tab on
[Printer Features] in the print dialog box.
Off
Disables image smoothing.
On
Performs image smoothing unconditionally.
Auto
Performs image smoothing automatically for images that have a resolution less than 25% of supported
printer resolution.
Less than 90 ppi - Less than 300 ppi
Performs image smoothing only when the image has an image resolution (pixels per inch) less than
the respective value you have selected in the list.
Printing a Document
99
3

Table of Contents

Other manuals for Ricoh Aficio MP C4000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio MP C4000 and is the answer not in the manual?

Ricoh Aficio MP C4000 Specifications

MP C4000

Power IconPower
power requirements120V, 12A, 60Hz
power consumption1, 500 Watts max.
Printing IconPrinting
output speed40 ppm Full-Color/BW
warm-up time34 seconds
first copy time (Full-Color)6.5 sec.
Paper Handling IconPaper Handling
document feeder capacity100 sheets
input capacityStandard: 2 x 550 sheets + 100-Sheet Bypass Tray
output capacityStandard: 500 sheets Face Down
Printer Controller IconPrinter Controller
CPUIntel Celeron-M 1.0 GHz
memory1 GB RAM and 160 GB HDD
max print resolution1200 x 1200 dpi
Weight and Dimensions IconWeight and Dimensions
dimensions26.4" x 26.7" x 30"
weightLess than 287 lbs. (130 kg)

MP C5000

Power IconPower
power requirements120V, 12A, 60Hz
power consumption1, 500 Watts max.
Printing IconPrinting
output speed50 ppm Full-Color/BW
warm-up time51 seconds
first copy time (Full-Color)5.9 sec.
Paper Handling IconPaper Handling
document feeder capacity100 sheets
input capacityStandard: 2 x 550 sheets + 100-Sheet Bypass Tray
output capacityStandard: 500 sheets Face Down
Printer Controller IconPrinter Controller
CPUIntel Celeron-M 1.0 GHz
memory1 GB RAM and 160 GB HDD
max print resolution1200 x 1200 dpi
Weight and Dimensions IconWeight and Dimensions
dimensions26.4" x 26.7" x 30"
weightLess than 287 lbs. (130 kg)
