Pull Front Cover Open Lever, and then open the front
cover with both
hands carefully.
D
Lower the blue fusing unit lever.
E
Using a coin, turn both gray knobs
on the fusing unit 90 degrees counter-
clockwise (until the slots are horizontal
ly aligned with the
marking
shown in the illustration below).
ASH01
1S
ASH046S
ASH127S
138
