Ricoh Aficio SP C232DN User Manual

Appendix
120
10
C Lower the blue fusing unit lever.
D Using a coin, turn both gray knobs on the fusing unit 90 degrees clockwise
(until the slots are vertically aligned with the marking shown in the illus-
tration below).
E Close the front cover with both hands carefully.
F Turn the power switch to On.
ASH046S
ASH128S
ASH067S

Ricoh Aficio SP C232DN Specifications

General

Brand	Ricoh
Model	Aficio SP C232DN
Category	Printer
Language	English
