Loading Paper
51
5
G Hold the tray with both hands, slide it along the rails of the printer body,
and then push it straight in.
To avoid paper jams, make sure the tray is securely inserted.
Note
❒ The upper limit differs depending on paper type; thin paper or thick pa-
per. Check the label inside the tray to confirm the upper limit.
Reference
For details about paper types supported by the printer, see p.39 “Paper
Recommendations”.
For details about the paper settings, see Software Guide.
Loading Legal size paper
This section describes how to load Legal size paper into the printer.
The same procedure applies to A4 paper (297 mm) or larger.
Important
❒ Do not move the side paper guide forcefully. Doing so can damage the tray.
❒ Do not move the end paper guide forcefully. Doing so can damage the tray.
❒ When inserting the tray, make sure it is not slanted. Inserting it at a slant can
damage the printer.
A Remove the rear cover using a coin.
ASH037S
ASH070S
To Next Page
