Ricoh Aficio SP C232DN User Manual

Replacing the Waste Toner Bottle
77
6
B Slide both levers on the front cover outward.
C Hold both ends of the transfer unit, and then lift it up.
D Hold the center of the waste toner bottle, and then carefully pull it out hor-
izontally.
ASH012S
ASH013S
ASH040S

Ricoh Aficio SP C232DN Specifications

General

Brand	Ricoh
Model	Aficio SP C232DN
Category	Printer
Language	English
