When the following message appears on the display, the toner should be replaced soon. Prepare new
toner.
" Out of toner. " " Toner is almost empty." In both messages, a combination of one to four colors,
(yellow, magenta, cyan, black) is shown to indicate the relevant toner.
When removing toner, be careful not to drop it.
Do not forcefully push toner in.
When handling toner containers, never stand them up on either end or position them upside down.
Store toner in a cool dark place.
Toner is a consumable and not covered by warranty. If there is a problem, contact the store where it
was purchased.
If cyan, magenta, or yellow toner runs out, you can print in black and white using black toner. Change
the color mode setting to Black and White using the printer driver.
If black toner runs out, you cannot print in black and white or color until the black toner is replaced.
1. Holding the left and right side grips, carefully open the front cover.
ASZ056S
From the left, the toner is installed in the order of black (K), yellow (Y), cyan (C), and magenta (M).
6. Replacing Consumables
114
6
