Installing the USB Host Interface Board
• Connect the USB cable from a digital camera to the USB host interface board.
• Connections between the USB host interface board and a computer are not supported.
• Before beginning work, ground yourself by touching something metal to discharge any static elec-
tricity. Static electricity can damage the USB host interface board.
• See p.63 "Digital Camera Connection" for details.
• Do not subject the USB host interface board to physical shocks.
1. Check the contents of the package.
When using a cable other than the one included with the board, attach the two included ferrite cores
to the cable.
2. Turn the printer off and unplug the power cable.
3. Loosen the two screws and remove the slot cover.
The removed cover will not be reused.
2. Installing Options
54
To Next Page
