9.
Slowly pull the thick paper out of the waste toner bottle vertically.
ASZ287S
10.
Holding the handle on the top, insert the waste toner bottle into the printer carefully.
ASZ117S
11.
When the
waste toner bottle is
inserted to the handle
area, push the
front side
of the waste
bottle to fully insert it into the printer.
ASZ118S
Replacing the Waste Toner Bottle
135
