4. If the paper could not be removed, open the front cover of the finisher.
ASZ271S
5. Raise the R2 lever.
ASZ191S
6. Turn the R3 knob counterclockwise to remove the paper.
ASZ192S
7. Return the R2 lever to its original position.
10. Removing Misfed Paper
208
