2. Remove the packaging from the paper feed unit.
3. Lift the 500-sheet paper feed unit, align it with the top of the 1000-sheet paper feed unit,
and slowly lower it straight down.
Place it so that it is held firmly in place by the vertical pins.
4. Pull the tray of the 500-sheet paper feed unit out slowly until it stops, then lift the front of
the tray slightly, and pull it out completely.
Place the tray on a flat surface.
5. Attach a screw in the hole on the left side of the tray opening to secure it to the paper feed
unit.
Tighten the screw firmly using a coin.
Attaching the Optional Paper Feed Unit
29
