4. Insert the expansion card into the slot until it clicks.
ATU030S
5. Reattach the slot cover ( ), and fasten the screws to secure it ( ).
ATU031S
Do not touch the card while the printer is in use. It may come loose, even if pushed only slightly. The
slot cover must be reattached.
Confirm that the card was correctly installed by printing the configuration page.
If the camera direct print card is installed properly, "PictBridge" will appear for “Connection Equip-
ment” in “System Reference”.
If the card is not installed properly, repeat the procedure from the beginning. If it cannot be installed
correctly even after reattempting installation, contact your sales or service representative.
For information on printing the configuration page, see "Test Printing", Quick Installation Guide.
"Test Printing", Quick Installation Guide
Installing a Camera Direct Print Card or Security Card
57
