Ricoh GR III User Manual

1
Introduction
17
5 Power button
Turns the power on or off. (p.40)
6 Movie/Wireless button (k/m)
Switches between still image mode and movie
mode. (p.54)
Press and hold to turn the wireless LAN function
on and off. (p.115)
7 Fn/Delete button (h/i)
Calls assigned function. (p.24)
In the playback mode, press to delete images.
(p.46)
8 ADJ./EV compensation lever
(n/o/q)
Press the lever to the left or right to change val-
ues for camera settings such as exposure.
In the shooting mode, press to switch to ADJ.
mode. (p.23)
9 ISO/Left button (u/c)
Press to change the ISO sensitivity. (p.64)
Moves the cursor to the left when an item is
selected.
10 MENU button (f)
Displays a menu. Press this button while the
menu is displayed to return to the previous
screen. (p.25)
11 White balance/Down button (t/b)
Displays the white balance setting screen.
(p.70)
Moves the cursor down when an item is se-
lected.
12 DISP button (j)
Switches the display between the shooting in-
formation and playback information. (p.20)
Press and hold this button in shooting mode to
magnify the Live View image. (p.45)
13 Playback button (g)
Switches between the shooting mode and the
playback mode. (p.46)
14 Macro/Up button (s/a)
Switches to macro mode. (p.61)
Moves the cursor up when an item is selected.
15 Control dial (r)
Rotate this dial to change menu items, values
for camera settings such as exposure, or images
to be displayed on the screen. (p.49)
16 Drive/Right button (v/d)
Displays the drive mode setting screen. (p.74)
Moves the cursor to the right when an item is
selected.
17 OK button (e)
Confirms the selected items such as menus.
Downloaded from ManualsNet.com search engine

Ricoh GR III Specifications

General

Megapixel	24.24 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	- \
Image formats supported	DNG, JPEG, RAW
Maximum image resolution	- pixels
Still image resolution(s)	-
Light metering	Centre-weighted, Highlight-weighted, Spot
ISO sensitivity	100, 102400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	102400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Optical zoom	- x
Fixed focal length	18.3 mm
Maximum aperture number	16
Minimum aperture number	2.8
Lens structure (elements/groups)	6/4
Maximum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Selective Auto Focus, Tracking Auto Focus
Closest focusing distance	0.1 m
Normal focusing range (tele)	- m
Photo effects	Vivid
White balance	Auto, Cloudy, Daylight, Manual, Shade, Tungsten
Camera playback	Single image
Self-timer delay	2, 10 s
Languages support	CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, THA, TUR
Camera file system	DCF 2.0, Exif 2.3
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Power source type	Battery
Battery type	DB-110
Battery life (CIPA standard)	200 shots
Cables included	USB
Video formats supported	AVC, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Audio system	stereo
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
USB connector	USB Type-C
Flash modes	Forced on, Red-eye reduction, Slow synchronization
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1037000 pixels
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Memory slots	1
Internal memory	2048 MB
Compatible memory cards	SD, SDHC, SDXC
Product color	Black

Weight and Dimensions

Depth	33.2 mm
Width	109.4 mm
Height	61.9 mm
Weight	227 g
Weight (including battery)	257 g
