Introduction
Connection Ports
15
6
11
15
10
Service
Computer InPC-Control
HDMI 1/MHL
Video In
Monitor Out
HDMI 2
Audio1 In
Audio Out Audio2 In S-Video In
LAN
32
The interface is
subject to model’s
specications.
Compatible with
MHL version 2.2,
the charging current
5V@0.9A.
N
o
t
e
1. S-Video In terminal
2. Monitor Out terminal
3. Computer In terminal
4. HDMI 1/MHL terminal
5. Service terminal
6. AC In socket
7. HDMI 2 terminal
8. PC-Control terminal
9. Audio1 In terminal
10. LAN terminal
11. Audio Out terminal
12. Audio2 In terminal
13. Video In terminal
4
6
5
89 710
1
11
12
13
