86
English
Appendices
Specications
■ List of general specications
Item
RICOH PJ X5461 RICOH PJ WX5461 RICOH PJ HD5451
DLP chip 0.55” DMD XGA 0.65” DMD WXGA 0.65” DMD 1080P
Lamp Type 260W lamp dimmable to 210W
Projection Lens F#2.5 - 2.93, f=15.98 - 21.42mm @ 60”, 1.36x Zoom Lens
Projection
Distance (Focus
range)
1.3~8.5m (Mechanical
Focus range)
1.3~7.2m (Mechanical Focus range)
Throw Ratio
(distance/width)
1.391 ~ 1.903 distance/
width @ 60”
1.113 ~ 1.523 distance/
width @ 60”
1.060 ~ 1.450 distance/
width @ 60”
Dimension
(WxDxH)
314.2 x 223.5 x 91.8 mm (without protruding part)
314.2 x 223.5 x 105.3 mm (with protruding part)
Weight Approx. 3.2 kg (7.05lb)
I/O Terminal
• HDMI1/MHL In
• HDMI 2 In
• Computer In
• Video In
• S-Video In
• Audio 1 In
• Audio 2 In
• Monitor Out
• Audio Out
• PC-Control
• LAN
• Service
Speaker 10W
Lamp life
• Normal: 3000 hours
• ECO: 6000 hours
Noise Level (Typ.)
• Full: Typical 37 dB (A) and maximum 39dB (A) at 23±2˚C for the full power mode
(260W)
• ECO: Typical 31 dB (A) and maximum 33 dB (A) at 23±2˚C for the eco mode (210W)
Environment
• Operational Temperatures
: 41° to 104°F (5° to 40°C); up to 80% humidity (non-condensing)
• Storage Temperatures
: -4° to 104°F (-20° to 60°C); up to 80% humidity (non-condensing)
Power
Consumption
• Eco Mode: Typ. 255W, max. 280W @ 110Vac; Typ. 245W, max. 270W @ 220Vac
• Full Mode: Typ. 320W, max. 352W @ 110Vac; Typ. 307W, max. 338W @ 220Vac
Standby Power 0.5W or less
• This model complies with the above specications.
• Designs and specications are subject to change without notice.
• This model may not be compatible with features and/or specications that may be added in the future.
N
o
t
e
■ Separately sold product
PJ Replacement Lamp Type 16
