Appendices
B. HDMI
(2) HDMI - Extended Wide Timing
Modes Resolution
V.Frequency
(Hz)
H.Frequency
(kHz)
WSVGA 1024 x 600 60 37.3
WXGA
1280 x 768 60 47.78
1280 x 768 75 60.29
1280 x 768 85 68.63
1280 x 720 60 44.8
1280 x 800 60 49.6
1366 x 768 60 47.71
WXGA+ 1440 x 900 60 55.9
WSXGA 1680 x 1050 60 65.3
WUXGA
1920 x 1080-RB 60 66.6
1920 x 1080-EIA 60 67.5
1920 x 1200-RB 59.95 74.04
(3) HDMI - Video Signal
480i 720 x 480 59.94(29.97) 27
480p 720 x 480 59.94 31.47
576i 720 x 576 50(25) 27
576p 720 x 576 50 31.25
720p 1280 x 720 60 45
720p 1280 x 720 50 37.5
1080i 1920 x 1080 60(30) 33.75
1080i 1920 x 1080 50(25) 33.75
1080p 1920 x 1080 60 67.5
1080p 1920 x 1080 50 56.25
1080p 1920 x1080 23.97/24 27
