6.3 JAM DETECTION
6.3.1 JAM DESCRIPTION AND POSITION CODE
 Position code: Shows the location of a jam. Appears on the operation panel.
These are lists of codes for the main machine and peripheral devices. Please note:
 Late jam. The paper has failed to arrive within the prescribed time due to a jam that has
occurred upstream of the referenced sensor.
 Lag jam. The paper has failed to leave the location of the referenced sensor within the
prescribed time due to a jam downstream of the referenced sensor.
Main Machine
No. Jam Description Position Code
1 Initial jam *1
2 Tray 1 no feed A
3 Optional PFU 1 no feed Y1
4 Optional PFU 2 no feed Y2
5 By-pass paper tray no feed A
6 Duplex no feed Z
7 Optional PFU 1 paper feed sensor: Late jam Y1
8 Registration sensor: Late jam A
10 Exit sensor: Late jam C
11 Optional PFU 1 paper feed sensor: Lag jam Y1
12 Optional PFU 2 paper feed sensor: Lag jam Y2
13 Registration sensor: Lag jam B
14 Exit sensor: Lag jam C
15 Exit sensor (duplex reverse): Lag jam Z
