Ricoh MP 2014 - Adf Cover Sensor;Original Set Sensor; Adf Pick-Up Solenoid

ADF Unit
SM 4-15 D245/D246/D247
Replacement
and Adjustment
4.4.8 ADF COVER SENSOR/ORIGINAL SET SENSOR
1. ADF rear cover (page 4-11)
2. ADF cover sensor [A] (
x 1, x 2)
3. Original set sensor [B] (
x 1, x 2)
4.4.9 ADF PICK-UP SOLENOID
1. ADF rear cover (page 4-11)
2. ADF pick-up solenoid [A] (
x 1, x 1)
