2.1.4 MACHINE DIMENSIONS
 DF Model (D247)
Width: 587 mm
Depth: 581 mm
Height: 537 mm
 Platen Model (D245/D246)
Width: 587 mm
Depth: 581 mm
Height: 461 mm
2.1.5 POWER REQUIREMENTS
 Make sure that the wall outlet is near the machine and easily accessible. After completing
installation, make sure the plug fits firmly into the outlet.
 Avoid multi-wiring.
 Be sure to ground the machine.
Input voltage:
Latin America 120V - 127V, 60Hz, 10A
Europe, Latin America, Asia,
China
220V - 240V, 50/60Hz, 5A
