Ricoh P C300W Field Service Manual

5.System Maintenance
137
Menu
Description
Inter. Rel.
Detect./2
Displays the interlock 2 status.
0: Door open, 1: Door closed
Fault Detection
Displays the failure status in order of
R8C, registration clutch, paper feed
clutch, bank feed clutch, bank transport
clutch, duplex motor.
0: Abnormal, 1: Normal
OUTPUT Check
Only one part can
be turned ON at a
time.
ITB Contact
Motor:CW
Rotates the ITB contact motor.
Waste Toner Motor
Rotates the waste toner collection motor.
Drum Mot. FC:
Low Spd
Rotates the color drum motor.
Drum Mot. FC:
Stand. Spd
Drum Mot. K: Low
Spd
Rotates the black drum motor.
Drum Mot. K:
Stand. Spd
Duplex:CW:
Middle Spd
Rotates the duplex motor forward.
Duplex:CW:
Stand. Spd
Duplex:CCW: Low
Spd
Rotates the duplex motor in reverse.
Duplex:CCW:
Middle Spd
Mot. FC:
CCW:Low Spd
Rotates the paper transport motor.
Note:
This cannot be used if the jam is
remaining in the machine except for non-
feed jam.
Mot. FC: CCW:
Stand. Spd
Fusing Fan
Operates the fusing fan.
Body Cooling Fan
Operates the LUS fan.
PSU Cooling Fan
Operates the PSU cooling fan.
Feed CL
Turns the paper feed clutch on.
Registration CL
Turns the registration clutch on.
Bank: Feed CL
Turns the bank paper feed clutch on.
