4.Replacement and Adjustment
27
Exterior Covers
Rear Cover
Printer Model
1. Remove the rear tray cover [A] and the interface cover [B].
2. Remove the rear cover [A].
There are some hooks inside the rear cover. Slide upward to release the hooks, and then remove
the rear cover.
