Ricoh P C300W Field Service Manual

5.System Maintenance
165
Menu
Des
[Off / On]
Sleep Mode Setting
[Off / On]
Test Pattern
Menu
Description
Test Pattern
Pattern Selection
Selects the test pattern.
[0 to 23 / 0 / 1/step]
• 0: None
• 1: Vertical line (1 dot)
• 2: Horizontal line (1 dot)
• 3: Vertical line (2 dots)
• 4: Horizontal line (2 dots)
• 5: Grid vertical line
• 6: Grid horizontal line
• 7: Grid pattern (20 mm)
• 8: Argyle pattern Small
• 9: Argyle pattern (20 mm)
• 10: Independent pattern (1 dot)
• 11: Independent pattern (2 dots)
• 12: Independent pattern (4 dots)
• 13: Full dot pattern
• 14: Band
• 15: Trimming frame (4 dots)
• 16: Trimming frame (2 dots)
• 17: Trimming frame (1 dots)
• 18 to 23: Not used
Color Selection
Selects the printing color.
[1 (All color) / 2 (Ma) / 3 (Ye) / 4 (Cy)]
Density: All
Sets the density.
[0 (Density 0%) to 15 (Density 100%) / 15 / 1/step]
Print Side Selection
Sets the printing side.
[0 (Single) / 1 (Duplex)]
Paper Size Selection
Selects the paper size.
[0 (LGT) / 1 (A4T) / 2 (B5T) / 3 (A5T)]
1 Sheet Printing
Prints out a test pattern.

Ricoh P C300W Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	30000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	60 - 163 g/m²
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB 2.0 ports quantity	1
Built-in processor	-
Sound pressure level (printing)	- dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Cables included	AC
Included cartridge capacity (black)	1000 pages

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
