Ricoh P C300W Field Service Manual

5.System Maintenance
172
Fax Service Test Menu (MF Model Only)
Entering the Fax Service Test Menu
For further information, contact the supervisor in your branch office.
Selecting an Item
Select the item which you want to execute.
Exiting the Fax Service Test Menu
Press [Exit].
Menu List
Menu
Description
Off-Hook Test
On Hook
Executes the on-hook test.
Off Hook
Executes the off-hook test
CED Test
Executes the CED test.
CNG Test
1100 Hz
Executes the CNG test
ANSam
Executes the ANSam test.
Ring Tone Test
Executes the ring tone test.
DTMF Test
Tone [0] to [9]
Executes the DTMF tone 0 to 9 test.
Tone [*]
Executes the DTMF tone * test.
Tone [#]
Executes the DTMF tone # test.
Tone Stop
Executes the Stop DTMF tone test.
Modem Test
[V34] 33600 bps
Generates the [V34] 33600 bps signal.
[V34] 28800 bps
Generates the [V34] 28800 bps signal.
[V17] 14400 bps
Generates the [V17] 14400 bps signal.
[V17] 12000 bps
Generates the [V17] 12000 bps signal.
[V17] 9600 bps
Generates the [V17] 9600 bps signal.
[V17] 7200 bps
Generates the [V17] 7200 bps signal.
[V29] 9600 bps
Generates the [V29] 9600 bps signal.
[V29] 7200 bps
Generates the [V29] 7200 bps signal.
[V27] 4800 bps
Generates the [V27] 4800 bps signal.
[V27] 2400 bps
Generates the [V27] 2400 bps signal.
[V21] 300 bps
Generates the [V21] 300 bps signal.
Signal Stop
Generates the Stop signal.

Ricoh P C300W Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	30000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	60 - 163 g/m²
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB 2.0 ports quantity	1
Built-in processor	-
Sound pressure level (printing)	- dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Cables included	AC
Included cartridge capacity (black)	1000 pages

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
