4.Replacement and Adjustment
56
AIO (All In One) Cartridge
AIO Cartridge
1. Open the top cover.
2. Hold the handle and pull out the AIO cartridge [A].
Black Drum Motor (M2)
1. Remove the left cover. (Left Cover)
2. Disconnect the fusing connector [A].
3. Release the two hooks to remove the fusing relay connector [A].
