4.Replacement and Adjustment
43
ADF Feed Roller
1. Open the ADF top cover.
2. Bend the rib [A] out slightly and then remove the original feed unit [B].
3. Remove the ADF feed roller [A].
After the installation, make sure that the gears turn properly.
ADF Pick-up Roller
1. Open the ADF top cover.
2. Bend the rib [A] out slightly and then remove the original feed unit [B].
