4.Replacement and Adjustment
93
15. Remove the fusing motor (M4) [A].
Registration Clutch (CL2)
1. Remove the left cover. (Left Cover)
2. Remove the fusing motor. (Fusing Motor (M4))
3. Remove the registration clutch (CL2) [A].
Paper Feed Roller
1. Remove all AIO cartridges. (AIO Cartridge)
2. Remove the waste toner bottle. (Waste Toner Bottle)
3. Remove the left cover. (Left Cover)
4. Remove the paper feed clutch. (Paper Feed Clutch (CL1))
5. Close the top cover and the front cover.
6. Pull out the paper tray.
