2. Remove the 4 screws and 3 connectors and separate the keypad board [B] and IR sensor
board [C] and FFC cable [D] from the top cover [A].
• When removing the IR sensor board, unfasten the 3 tenons.
Zoom ring
1. Top cover unit (page 26 "Top cover unit")
3. Replacement and Adjustment
28
