2. Remove the 1 screw to remove the thermistor [A].
Color wheel
1. Photo sensor board (page 38 "Photo sensor board")
2. Thermistor (page 39 "Thermistor")
3. Remove the 2 screws to remove the color wheel module and color wheel holder [A].
3. Replacement and Adjustment
40
