2. Remove the 1 screw, and then remove the zoom ring [A] from the top cover [B].
3. Separate the bracket [A] and zoom ring [B].
Control panel / Top cover
1. Keypad board / IR sensor board (page 27 "Keypad board / IR sensor board")
Part Replacement
29
