Available Features Self-Defining Field
Since printers are capable of supporting multiple features, multiple configuration combinations are
possible. All available features are described below.
Offset Range Meaning
0-1 X'000C' or
X'000E'
LENGTH of this Self Defining Field
2-3 X'0007' AVAILABLE FEATURES Self Defining Field
4-5 X'0100' DUPLEX
6-7 X'0300' CUT SHEET Output
8-9 X'0600' OFFSET STACKER
10-11 X'0700' Envelope
12-13 X'0800' MICR (If MICR Enabled)
RRL Resource Type and ID Format Self-Defining Field - Single Byte
Offset Range Meaning
0-1 X'0022' VECTOR LENGTH
2-3 X'000A' RRL RESOURCE TYPE Self
RRL query combinations that receive a non-zero Resource Type reply (See
page 64 "XOA Request Resource List")
4-5 X'0100' Single-Byte Coded Fonts as Host Assigned Resource ID
6-7 X'0103' Single-Byte Coded Fonts as IBM Global Resource ID
8-9 X'0400' Page Segments as Host Assigned Resource ID
10-11 X'0500' Overlays as Host Assigned Resource ID
12-13 X'0600' Device Version Code Pages as Host Assigned Resource ID
14-15 X'0603' Device Version Code Pages as IBM Global Resource ID
16-17 X'0700' Font Character Set as Host Assigned Resource ID
18-19 X'0703' Font Character Set as IBM Global Resource ID
1. Device Control Command Set
