User Code Authentication
This is an authentication method for limiting access to functions according to a user code. The same user
code can be used by more than one user. For details about specifying user codes, see Web Image
Monitor Help.
For details about specifying the user code for the printer driver, see the printer driver Help.
1. Log in as the machine administrator from Web Image Monitor.
2. Point to [Device Management], and then click [Configuration].
3. Click [User Authentication Management] under "Device Settings".
4. Select [User Code] in the "User Authentication Management" list.
5. In "Functions to Restrict", select the printer's functions you want to limit.
To enable printer job authentication, select any option other than [PC Control].
6. Select the "Printer Job Authentication" level.
For details about the printer job authentication levels, see page 57 "Printer Job Authentication".
If you select [Entire] or [Simple (All)], proceed to Step 8.
If you select [Simple (Limitation)], proceed to Step 7.
7. Specify the range in which [Simple (Limitation)] is applied to "Printer Job Authentication".
You can specify the IP address range to which this setting is applied. Also, you can specify whether
or not to apply the setting to the parallel and USB interfaces.
8. Click [OK].
9. Log out.
1. Log in as the machine administrator from the control panel.
2. Display the screen for configuring User Code authentication.
[System Settings] [Administrator Tools] [User Authentication Management] [User Code
Authentication] [OK]
3. Display the screen for configuring Authentication Information.
[User Authentication Management] [Authentication Info] next to [User Code Authentication]
4. Select the functions you want to restrict using User Code Authentication.
[Restrict Other Functions] Select the functions you want to restrict [OK]
2. Configuring User Authentication
34

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP 4510dn and is the answer not in the manual?

Ricoh SP 4510dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLED
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)5 s
Print speed (black, normal quality, A4/US Letter)40 ppm
Printing colorsBlack
Maximum duty cycle150000 pages per month
Number of print cartridges1
Page description languagesPCL 5e, PCL 6
Total input capacity600 sheets
Maximum input capacity1600 sheets
Paper tray media typesPlain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight52 - 162 g/m²
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-purpose tray media typesLetterhead
Maximum ISO A-series paper sizeA4
Wi-Fi-
Supported network protocols (IPv4)TCP/IP
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
Storage mediaHDD
Internal memory512 MB
Maximum internal memory1536 MB
Internal storage capacity320 GB
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)1110 W
Power consumption (printing)- W
Power consumption (PowerSave)1 W
Product colorGrey, White
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth392 mm
Width370 mm
Height306 mm
Weight14000 g
