Coordinate System
Xm, Ym Coordinate System (Medium Presentation Space)
The Xm, Ym coordinate system is the medium presentation space coordinate system. The origin of this
system (Xm=0, Ym=0) can be set by the IPDS XOH Set Media Origin command to any of the four
corners of the media. If this command is not sent to the printer the origin is the top-left corner (viewed
from the center). In this case, positive Xm values begin at the origin and increase along the top edge
from left to right. Positive Ym values begin at the origin and increase along the left side from top to
bottom. Top is defined as the short edge which leads into the printer. See Intelligent Printer Data Stream
Reference for a description of the Xm, Ym Coordinate System and default media origin for envelopes.
Xp, Yp Coordinate System (Logical Page Presentation Space)
Identifying the Size of the Logical Page or Overlay
The size of the logical page or overlay presentation space is set during a printer initialization using the
"IPDS Initialization Defaults" or by the host program when it sends a Logical Page Descriptor command.
Overlays are logical pages and are handled as such by the printer with the following special
considerations:
1.
Overlays are positioned in relationship to the logical page presentation space origin (Xp=0, Yp=0)
when they are merged with the Include Overlay command.
2. Overlays are positioned in relationship to the origin of the medium presentation space (Xm=0,
Ym=0) when they are merged with the Merge Overlay keyword in a copy control record.
• For details about the "IPDS Initialization Defaults", see page 39 "IPDS Initialization Defaults".
I, B Coordinates System (Text)
The +I and +B directions for the logical page or overlay are specified in degrees of rotation in
relationship to the +Xp direction on the logical page.
The printer sets the +I and +B directions during the initialization through the "IPDS Initialization Defaults".
The host program can change the +I and +B directions through the Logical Page Descriptor command
(See Intelligent Printer Data Stream Reference).
The host program can also change the +I and +B directions as it builds a page or overlay through text
controls in the print data sent by a Write Text command (See "Write Text", IPDS Technical Reference 2).
Coordinate System
27

Ricoh SP 4510dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Total input capacity	600 sheets
Maximum input capacity	1600 sheets
Paper tray media types	Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Letterhead
Maximum ISO A-series paper size	A4
Wi-Fi	-
Supported network protocols (IPv4)	TCP/IP
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Internal memory	512 MB
Maximum internal memory	1536 MB
Internal storage capacity	320 GB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1110 W
Power consumption (printing)	- W
Power consumption (PowerSave)	1 W
Product color	Grey, White
Cables included	AC

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	306 mm
Weight	14000 g
