• Setting the orientations of the +I and +B axes also implicitly sets their origins as one of the four
corners of the logical page or overlay.
• For details about the "IPDS Initialization Defaults", see page 39 "IPDS Initialization Defaults".
Other Text Positioning Terms
Some other terms that relate to text positioning and fonts include:
Text Orientation
The combination of the inline sequence direction (the direction which characters are added to a line)
and the baseline sequence direction (the direction which lines are added to a page or overlay) identify
the text orientation for a page. The inline sequence direction can be 0, 90, 180 or 270 degrees. The
machine supports baseline sequence directions that are always rotated plus or minus 90 degrees from
the inline sequence direction. Therefore, there are eight text orientations for printing pages or overlays.
Printing Baseline
An imaginary line that extends across the page or overlay in the positive inline sequence direction (+I),
between pixels, and beginning from the baseline sequence printing coordinate (Bc). (Sometimes shown
as baseline as in the font terms baseline offset and baseline extent.)
In languages with a right to left or left to right reading order (for example, English), the printing baseline
is the imaginary line on which the main body of the character appears to rest. Descenders (the "tails" of
lower case g, j, p, q, and y characters) usually extend below the printing baseline.
In languages with a top to bottom reading order (for example, Kanji), the printing baseline is an
imaginary vertical line that passes through the center of the character.
Each font index record contains a Font Inline Sequence field. The field value specifies a relationship
between the inline sequence direction and the font rotation (the character pattern rotation for the font).
The printer uses the font index record to identify how to place characters on the printing baseline for a
page or overlay. The characters are placed in the combination of the inline sequence direction (the
printing direction) and the font rotation.
The Baseline Offset value is another field in the font index record. This value locates the printing baseline
relationship to a specified character box reference edge.
1. IPDS Overview
28

Ricoh SP 4510dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Total input capacity	600 sheets
Maximum input capacity	1600 sheets
Paper tray media types	Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Letterhead
Maximum ISO A-series paper size	A4
Wi-Fi	-
Supported network protocols (IPv4)	TCP/IP
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Internal memory	512 MB
Maximum internal memory	1536 MB
Internal storage capacity	320 GB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1110 W
Power consumption (printing)	- W
Power consumption (PowerSave)	1 W
Product color	Grey, White
Cables included	AC

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	306 mm
Weight	14000 g
