Ricoh SP 4510dn User Manual

5. Graphics Command Set
Graphics Commands
The base reference for graphic drawing orders is the Graphics Object Content Architecture Reference.
Name Command Sub-command Where to Look
Write Graphics Control X'D684' page 147 "Write
Graphics Control"
Graphics Area Position X'AC6B' page 147 "Graphics
Area Position"
Graphics Output
Control
X'A66B' page 148 "Graphics
Output Control"
Graphics Data
Descriptor
X'A6BB' page 150 "Graphics
Data Descriptor"
Write Graphics X'D685' page 155 "Write
Graphics"
Begin Segment
Introducer
X'70' page 156 "Begin
Segment Introducer"
Write Graphics Control
Graphics Area Position
Offset Range Meaning Error Code
0-1 X'000B'-
X'xxxx'
LENGTH of Graphics Area Position X'0202..0
5'
2-3 X'AC6B' Structured Field ID. X'020B..
05'
4-5 X'8000'-
X'7FFF'
GRAPHICS BLOCK ORIGIN Xp, I, or I-offset Coordinate
Position.
See "Notation Conventions", IPDS Technical Reference 1.
147

Ricoh SP 4510dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Total input capacity	600 sheets
Maximum input capacity	1600 sheets
Paper tray media types	Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Letterhead
Maximum ISO A-series paper size	A4
Wi-Fi	-
Supported network protocols (IPv4)	TCP/IP
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Internal memory	512 MB
Maximum internal memory	1536 MB
Internal storage capacity	320 GB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1110 W
Power consumption (printing)	- W
Power consumption (PowerSave)	1 W
Product color	Grey, White
Cables included	AC

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	306 mm
Weight	14000 g
