Registering the Printer
To use the printer, the printer must be registered in the printer list.
Make sure the printer and computer are connected and turned on, and perform the following
procedure.
For details about how to connect the printer to the computer, see "Connecting the Printer" HTML manual.
When printing with a USB connection to a Macintosh computer, the printer language does not
change automatically. Use the control panel on the printer to change the printer language to [Auto
Detect] or [PS] before printing.
The operating procedure under Mac OS X differs depending on the version of the operating
system. Check the procedure described in this manual, and configure the necessary settings
according to the manual for each version.
USB Connection
Make sure the computer and the printer are connected using the USB cable, and the power of the
devices has been turned on.
1. Start System Preferences.
2. Click [Print & Fax] or [Print & Scan].
3. Click the [ ] button.
4. Click [Default Browser] or [Default].
5. Select the printer that has "USB" indicated in the [Connection] or [Kind] column.
6. Select the printer you are using from the [Print Using:] or [Use:] pop-up menu.
If the printer you are using is not selected in [Print Using:] or [Use:], select its manufacturer, [Select a
driver to use...], or [Select Printer Software...] in the pop-up menu, and then select the PPD file of the
printer. For the location of the PPD files, see page 35 "Installing PPD Files".
7. Click [Add].
If option settings need to be configured, click [Configure...] in the dialog box that appears, and
then configure the option settings.
8. Quit System Preferences.
7. Installing the Printer Driver Under Mac OS X
36

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP 4510dn and is the answer not in the manual?

Ricoh SP 4510dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLED
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)5 s
Print speed (black, normal quality, A4/US Letter)40 ppm
Printing colorsBlack
Maximum duty cycle150000 pages per month
Number of print cartridges1
Page description languagesPCL 5e, PCL 6
Total input capacity600 sheets
Maximum input capacity1600 sheets
Paper tray media typesPlain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight52 - 162 g/m²
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-purpose tray media typesLetterhead
Maximum ISO A-series paper sizeA4
Wi-Fi-
Supported network protocols (IPv4)TCP/IP
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
Storage mediaHDD
Internal memory512 MB
Maximum internal memory1536 MB
Internal storage capacity320 GB
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)1110 W
Power consumption (printing)- W
Power consumption (PowerSave)1 W
Product colorGrey, White
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth392 mm
Width370 mm
Height306 mm
Weight14000 g
